EXCAVATOR PILE DRIVING ARM & BOOM

The CAT 336 Piling Arm is a heavy-duty excavator attachment specially engineered for Caterpillar 336 series excavators (36-ton class), designed to support efficient and stable pile driving operations in foundation and infrastructure projects.

This piling boom is widely used in bridge construction, port and wharf projects, highway foundations, solar pile installation, and industrial civil works, where precise vertical alignment and strong structural stability are required.

The arm structure adopts reinforced box-type design using high-strength steel, ensuring excellent rigidity and vibration resistance when operating with vibro hammers or hydraulic pile drivers. Optimized center-of-gravity positioning helps maintain machine balance during lifting and pile driving operations.

Each CAT 336 piling arm is custom-manufactured according to hammer type, pile length, and jobsite requirements, offering a reliable and adaptable solution for contractors working under demanding conditions.

 ▎KEY FEATURES

✔ Heavy-Duty Reinforced Structure

Designed for continuous pile driving with high impact loads.

✔ Stable Vertical Control

Ensures accurate pile positioning and reduced deviation.

✔ Optimized Weight Distribution

Improves machine stability during lifting and driving.

✔ Wide Hammer Compatibility

Suitable for vibro hammers and hydraulic pile drivers.

✔ Custom Engineering Support

Arm length and mounting designed per project needs.

 ▎CONFIGURATION SITUATION

 ▎STEEL CUTTING

The incision is flat to ensure the accuracy of cutting steel plates

 ▎GROOVE WELDING

Before welding, we have use big edge milling machine mill(taper process) the edge of the sheet. So the welding can go to the internal of the steel-sheet and make the structure have higher performance.

Orbital welding machines are used for welding, and manual strengthening and welding are performed at corners and reinforcements.

Our boom and arm are large-welded box structure and thick or multi-plates for high-stress areas.

Also the inside have strength plate make it more stronger.

 ▎LARGE BORING MACHINE -- BUTT BORING

The processing efficiency is higher, the precision is better, and the product quality and labor efficiency are greatly improved.

 ▎SURFACE TREATMENT OF WORKPIECE--SHOT BLAST

The small steel balls of the large shot blasting machine are used to hit the surface of the workpiece to remove the rust and small impurities on the surface of the steel plate, so that the surface of the workpiece presents the original metallic luster and increases the adhesion of the primer.

 ▎PRIMER AND PAINT TREATMENTS

Spray with the same paint as the brand excavator factory to ensure consistent color.

 ▎HIGH PRESSURE HARD PIPE & PIPELINE BENDING TREATMENT

1. Friction welded flange and oil cylinder - use machine high-speed friction welding, which has higher efficiency and avoids artificial false welding and air bubbles.

2. Automatic pipe bending machine - use numerical control to control the degree of bending of the pipeline, and automatically bend the seamless steel pipe, with higher precision.

 ▎PAINT / PACKAGING / TRANSPORTATION SERVICES

1.The color paint is consistent with the brand excavator factory (customizable color), using high-quality paint to make the product more delicate and beautiful.

2. We use stretch film to package the product. (Three-plywood wooden frame needs to be noted)

3. We have cooperated with many shipping companies in China for many years,and the transportation service and efficiency are very good. (Recommend FOB/CIF/CNF)
